PREVIEW: THE PIXEL WINDOW
PVC WINDOW THAT COMBINES MODERNITY & LUMINOSITY
Anthracite grey alux
Black
Mahogany
Anthracite wood
White
Golden Oak
Sheffield oak
Swamp oak
Sienna rosso
Winchester
Natural light is indispensable to us. Its benefits are countless: it improves morale, stimulates alertness, regulates the internal clock or synchronizes sleep.
To let this natural light flood into our interiors, OKNOPLAST, a European leader in PVC windows, doors and shutters, has put all its know-how into the design of a revolutionary new window with a contemporary, narrower profile (with a 70mm frame) and with enlarged clear glazing: the PIXEL
With its exceptional design with angular shapes, the new PIXEL OKNOPLAST window responds to the latest architectural trends with more modern, unrounded shapes. Much more than a window, the PIXEL is a decorative and design element that sublimates the home.
Technical performance
To abolish the boundaries between inside and outside, this new OKNOPLAST window offers 22% more light than a standard window. Thanks to its slim central opening (112 mm wide), this pixel window brings great clarity to interiors.
This additional light supply, combined with remarkable thermal performance, not only guarantees well-being, but also a significant reduction in energy consumption.
At the cutting edge of the latest innovations on the market, the PIXEL window combines design and technology for more light, and gives another dimension to the window of the Oknoplast range.
While its ultra-thin, straight profile optimizes brightness, it also gives Oknoplast’s new PIXEL window a contemporary design. In addition to the handle centred on the two-leaf PIXEL window, there is a very rich range of basic equipment for optimal comfort of use. It thus includes an anti-misuse mechanism, a leaf lifter, a stop in the falling position and a multi-position inter-door.
The new PIXEL window is also very thermally efficient. The “Research and Development” teams at OKNOPLAST have improved its insulation capacity thanks to a 6-chamber profile and a 70 mm Class A chassis which guarantee sound protection and eliminate heat loss, air infiltration and condensation.
On the glazing side, it is equipped as standard with reinforced thermal double glazing (4/16/4) with argon filling (insulating gas). The PIXEL window is also available in triple glazing (3/14/3/14/3) ensuring Ug coefficients at 0.6 W/m2K and Uw at 0.9 W/m2K. Thanks to the thermal performance of its glazing, it avoids heat loss and the effect of cold walls inside the home. This multi-room structure is the key to significant energy saving.
OKNOPLAST has equipped its new PIXEL window with a new generation of equipment designed to ensure the security of goods and persons: patented sash and frame reinforcements, double security point, burglar-proof glazing, as well as two security latches.
Latches which, by enclosing the mushroom-shaped roller when the window is closed, make it very difficult to remove the window with a crowbar. The resistance classes RC1 or RC2 are available as options.
DOUBLE GLAZING 4/16/4 | TRIPLE GLAZING 3/14/3/14/3 |
Ug: 0,26 BTU(th)/h•ft²•°F Uw: 0,29 BTU(th)/h•ft²•°F SHGC: 0,43 |
Ug: 0,12 BTU(th)/h•ft²•°F Uw: 0,2 BTU(th)/h•ft²•°F SHGC: 0,36 |
All products, images and colors are for reference and may differ from real products.
